Main Specifications
Capacity
| SPECIFICATIONS | UNITS | MODELS | |
|---|---|---|---|
| PFG-1545M | PFG-2045M | ||
Table Size |
mm | 150 x 450 | 200 x 450 |
Max. Grinding Surface |
mm | 150 x 450 | 200 x 450 |
Max. Distance Center Of Spindle To Table |
mm | 450 | 450 |
Table Speed |
m/min | Manual | |
Table Guideway |
Type | Ball rolling way | |
Rapid Power Cross Feed approx. |
mm/min | Manual | |
Cross Feed On Hand Wheel |
1 rev.(1 gra.) | 5 mm (0.02 mm) | |
Rapid Power Head Elevation Approx. (Option) |
60Hz (50Hz) | 550 mm/min (450 mm/min) | |
Vertical Feed On Hand Wheel |
1 rev.(1 gra.) | 2.0 mm (0.01 mm / 0.005mm with AD5) | |
Auto Down Feed (Option) |
mm/time | 0.001 ~ 0.999 | |
Wheel Speed |
rpm | 3500(60Hz) / 2900(50Hz) | |
Wheel Dimension |
mm | 180 x 13 x 31.75 (Max. 200 x 20 x 31.75) | |
Spindle Motor |
Hp | 2 | |
Rapid Head Elevation Motor |
Hp | 1/5 (Optional) | |
Machine Floor Space |
(L x W)mm | 1900 x 1200 | 2100 x 1200 |
Machine Height |
mm | 1950 | 1950 |
Machine Weight |
kg | 870 | 920 |
Standard Accessories
| . Grinding Wheel | . Flange Extractor | . Wheel Dresser With Diamond |
| . Wheel Flange | . Wheel Balancing Arbor | . Levelling Bolts And Pads |
| . Work Lamp | . Wheel Balancing Stand | . Tool Box With Adjustment Tools |
Optional Accessories
| . Cross / Vertical Micro Feed | . Suction With Coolant System | . Auto Paper Filter & Amp; Mag. Separator |
| . Wheel Flange (extra) | . Electro / Permanent Magnetic Chuck | . Rapid Up / Down System |
| . Parallel Dresser | . Demagnetizer For Work Piece | . Auto Down Feed System |
| . Coolant System (1/8HP) | . Auto Demagnetizer For Mag. Chuck | . Auto Cross Stroke Adjustment |
| . Suction System (1/2HP) | . Auto Paper Filter With Coolant | . Auto Balancing Device |
 |
